A white dome security camera with a black lens cover and the PRAMA logo printed in blue on the side, set against a plain white background.

Prama PT-NC147D3-WNRAM(D2) 4MP Dual Light Varifocal Dome Camera | 2.8–12mm | 30m | 120dB WDR | 512GB | PoE | IP67 | 1 Year Warranty

SKU: PT-NC147D3-WNRAM(D2)

In Stock
0 people are currently viewing this product
₹ 14,899
Taxes included. Free Shipping.
Exclusive Pricing Available
Connect with our team for personalised pricing and the latest available offers on this product. Contact us
4.6
(285 reviews)

ADD-ON PRODUCTS

COMPARE

DESCRIPTION

Prama PT-NC147D3-WNRAM(D2) 4MP Dual Light Varifocal Dome Camera | 2.8–12mm | 30m | 120dB WDR | 512GB | PoE | IP67 | 1 Year Warranty

Product Description

The Prama PT-NC147D3-WNRAM(D2) is a 4MP Dual Light Varifocal Dome Network Camera designed for professional indoor and outdoor surveillance. It delivers 2560 × 1440 resolution and features a 2.8–12mm motorized varifocal lens for flexible monitoring and installation. The camera supports IR and white-light illumination up to 30 metres, human and vehicle classification, 120dB WDR, H.265/H.264 compression, built-in microphone, microSD storage up to 512GB, PoE and IP67 protection.

Available from Suntronix, a trusted Prama Dealer in Chennai, Tamil Nadu, with product availability and delivery across India.


About This Product

The Prama PT-NC147D3-WNRAM(D2) combines 4MP high-resolution imaging with Dual Light technology and a motorized varifocal lens. Its 1/3-inch Progressive Scan CMOS sensor supports up to 2560 × 1440 resolution, while the 2.8–12mm motorized varifocal lens provides a flexible horizontal field of view from 96.7° to 29.7°.

The camera provides 120dB WDR, BLC, HLC and 3D DNR for enhanced image quality in challenging lighting conditions. It also supports human and vehicle classification, built-in audio, onboard storage up to 512GB, alarm input/output, IEEE 802.3af PoE, and IP67 protection.


Key Features

  • 4MP Dual Light Varifocal Dome Network Camera
  • 2560 × 1440 Maximum Resolution
  • 1/3-inch Progressive Scan CMOS
  • 2.8–12mm Motorized Varifocal Lens
  • IR + White Light
  • Up to 30m Supplement Light Range
  • Smart Supplement Light
  • Human & Vehicle Classification
  • 120dB WDR
  • BLC / HLC / 3D DNR
  • H.265 / H.264 Compression
  • Built-in Microphone
  • microSD Storage up to 512GB
  • 1 Alarm Input + 1 Alarm Output
  • IEEE 802.3af PoE
  • ONVIF Profile S, G & T
  • IP67 Protection
  • Up to 6-Channel Simultaneous Live View

Storage

The Prama PT-NC147D3-WNRAM(D2) features a built-in memory card slot supporting microSD, microSDHC and microSDXC cards up to 512GB, providing onboard storage flexibility for surveillance recording.


Ideal Applications

The Prama PT-NC147D3-WNRAM(D2) is suitable for:

  • Homes & Apartments
  • Offices & Corporate Spaces
  • Retail Stores
  • Shops & Showrooms
  • Warehouses
  • Commercial Buildings
  • Educational Institutions
  • Industrial Facilities
  • Parking Areas
  • Outdoor Perimeter Security
  • Residential Communities
  • Professional CCTV Installations

Why Buy from Suntronix?

With over 25 years of industry experience, Suntronix provides genuine Prama security and surveillance solutions in Chennai, Tamil Nadu, and across India. Get professional assistance for IP cameras, NVRs, CCTV systems, surveillance storage and complete security solutions.

SPECIFICATION

Brand

Prama

Model

PT-NC147D3-WNRAM(D2)

Product Type

4MP Dual Light Varifocal Dome Network Camera

Image Sensor

1/3-inch Progressive Scan CMOS

Maximum Resolution

2560 × 1440

Minimum Illumination

Colour: 0.005 Lux @ F1.6, AGC ON
B/W: 0 Lux with IR

Shutter Time

1/3s to 1/100,000s

Day & Night

IR Cut Filter

Angle Adjustment

Pan: 0° to 355°
Tilt: 0° to 70°
Rotate: 0° to 355°

Lens Type

Motorized Varifocal Lens

Focal Length

2.8–12mm

Field of View

Horizontal: 96.7° to 29.7°
Vertical: 51.7° to 16.7°
Diagonal: 114.3° to 34°

Lens Mount

Ø14

Iris Type

Fixed

Aperture

F1.6

DORI Distance

Detect: 64.0–198.0m
Observe: 25.4–78.6m
Recognize: 12.8–39.6m
Identify: 6.4–19.8m

Supplement Light Type

IR + White Light

Supplement Light Range

Up to 30m

Smart Supplement Light

Yes

IR Wavelength

850nm

Main Stream

50Hz: 20fps at 2560 × 1440; 25fps at 1920 × 1080 / 1280 × 720
60Hz: 20fps at 2560 × 1440; 24fps at 1920 × 1080 / 1280 × 720

Sub Stream

50Hz: 25fps at 1280 × 720 / 640 × 480 / 640 × 360
60Hz: 24fps at 1280 × 720 / 640 × 480 / 640 × 360

Video Compression

Main Stream: H.265 / H.264
Sub Stream: H.265 / H.264 / MJPEG

Video Bit Rate

32Kbps to 16Mbps

Bit Rate Control

CBR / VBR

H.264 Profile

Baseline Profile / Main Profile / High Profile

H.265 Profile

Main Profile

Scalable Video Coding

H.264 and H.265 Encoding

Region of Interest

1 Fixed Region for Main Stream

Audio

Mono Sound

Built-in Microphone

Yes

Audio Compression

G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC

Audio Bit Rate

64Kbps G.711ulaw/G.711alaw
16Kbps G.722.1
16Kbps G.726
32–160Kbps MP2L2
16–64Kbps AAC-LC

Audio Sampling Rate

8kHz / 16kHz

Environment Noise Filtering

Yes

Wide Dynamic Range

120dB WDR

SNR

≥52dB

Image Enhancement

BLC / HLC / 3D DNR

Privacy Mask

4 Programmable Polygon Privacy Masks

Target Classification

Human & Vehicle Classification

Network Interface

1 × RJ45 10M/100M Self-Adaptive Ethernet Port

ONVIF

Profile S / Profile G / Profile T

Simultaneous Live View

Up to 6 Channels

Onboard Storage

Built-in memory card slot supporting microSD / microSDHC / microSDXC up to 512GB

Built-in Microphone

Yes

Audio Interface

1 Audio Input + 1 Audio Output

Alarm Interface

1 Alarm Input + 1 Alarm Output

Reset Key

Yes

Event Detection

Motion Detection with specified target types including human and vehicle, video tampering alarm and exception

Linkage

Upload to FTP/SFTP/memory card, notify surveillance centre, send email, trigger recording, trigger capture, audible warning and trigger alarm output

Power Supply

12VDC ±25%, 0.8A

PoE

IEEE 802.3af, Class 3

Maximum Power Consumption

12VDC: Maximum 9.6W
PoE: Maximum 12W

Material

Base: Metal
Cover: Plastic

Protection Rating

IP67

Dimensions

Ø121.5 × 97.6mm

Weight

Approximately 540g

Package Dimensions

150 × 150 × 141mm

Package Weight

Approximately 740g

Operating Temperature

-30°C to +60°C

Operating Humidity

95% or less, non-condensing

General Function

Heartbeat, anti-banding, mirror, password protection and password reset via email
