Description
Powerful AMD Ryzen Processor: The NAS is equipped with an AMD Ryzen V1500B quad-core/eight-thread 2.2 GHz processor. This ensures robust performance, allowing it to handle resource-demanding applications and multitasking efficiently.
High-Speed Network Connectivity: Featuring dual 2.5GbE ports, the TS-1673AU-RP-16G supports port trunking, providing up to 5Gbps combined bandwidth. This results in fast data transfer speeds and reliable network performance, suitable for demanding network environments.
Versatile Expansion Options: The NAS includes two PCIe Gen 3 slots, which allow for the installation of additional cards such as 10GbE/25GbE network cards, QM2 cards for M.2 SSD caching, or USB 3.2 Gen 2 cards. This flexibility enhances the NAS's functionality to meet various performance needs.
Redundant Power Supply for Reliability: The TS-1673AU-RP-16G comes with redundant power supplies, ensuring maximum system uptime and reliability. This feature is crucial for maintaining continuous access to your data in mission-critical environments.
Comprehensive Data Protection: The NAS supports AES 256-bit encryption to protect sensitive business data without impacting system performance. Additionally, it offers snapshot technology to safeguard your files and data from accidental deletion and malware attacks.
Model | TS-1673AU-RP-16G |
CPU | AMD Ryzen Embedded V1500B 4-core/8-thread 2.2 GHz processor |
CPU Architecture | 64-bit x86 |
System Memory | 16 GB UDIMM DDR4 (1 x 16 GB) |
Maximum Memory | 64 GB (2 x 32 GB) |
Memory Slot | 2 x UDIMM DDR4 Support ECC memory |
Flash Memory | 5GB (Dual boot OS protection) |
Drive Bay | 16 x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility |
3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
M.2 Slot | Optional via a QNAP QM2 PCIe card |
2.5 Gigabit Ethernet Port | 2 (2.5G/1G/100M/10M) |
PCIe Slot | 2 x PCIe Gen3 x4 |
USB 3.2 Gen 1 port | 1 x Type-A |
USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-C 1 x Type-A |
Form Factor | 3U Rackmount |
LED Indicators | HDD 1-16 Status LAN USB Power |
Buttons | Power, Reset |
Operating Temperature | 0 - 40 °C (32°F - 104°F) |
Power Supply Unit | 550W (x2), 100-240V AC, 50-60Hz, 7-3.5A |
Power Consumption | Disk Standby Mode: 47.75 Operating Mode: 97.34 W |
Fan | 3 x 80mm, 12VDC |
System Warning | Buzzer |
Standard Warranty | 3 Years |
Dimensions | 131.3 × 432 × 370.9 mm |
Package Contents | TS-1673AU-RP Ethernet Cable x 1 Power Cord x 2 Flat head screw (for 3.5" HDD) x 64 Flat head screw (for 2.5" HDD) x 48 Quick Installation Guide (QIG) |
