Description
Powerful Quad-Core Processor: The NAS is equipped with an Intel Celeron N5095 quad-core processor, capable of bursting up to 2.9 GHz. This ensures robust performance, allowing it to handle various applications and multitasking efficiently.
Compact and Space-Efficient Design: With its short-depth 2U form factor, the TS-864eU-RP-8G is ideal for installation in small media cabinets or environments with limited space. This design makes it easy to manage and integrate into existing setups.
High-Speed Network Connectivity: Featuring dual 2.5GbE ports, the NAS supports port trunking, providing up to 5Gbps combined bandwidth. This results in fast data transfer speeds and reliable network performance, suitable for demanding network environments.
Versatile Expansion Options: The NAS includes a PCIe Gen 3 slot, which allows for the installation of additional cards such as 10GbE/5GbE network cards, QM2 cards for M.2 SSD caching, or USB 3.2 Gen 2 cards. This flexibility enhances the NAS's functionality to meet various performance needs.
Enhanced Data Protection and Reliability: The TS-864eU-RP-8G comes with redundant power supplies, ensuring maximum system uptime and reliability. It also supports AES 256-bit encryption and snapshot technology to safeguard your data against accidental deletion and malware attacks.
Model | TS-864eU-RP-8G |
CPU | Intel Celeron N5095 4-core/4-thread processor, burst up to 2.9 GHz |
CPU Architecture | 64-bit x86 |
Graphic Processors | Intel UHD Graphics |
System Memory | 8 GB SODIMM DDR4 (1 x 8 GB) |
Maximum Memory | 16 GB (2 x 8GB) |
Flash Memory | 4GB (Dual boot OS protection) |
Drive Bay | 8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
2.5 Gigabit Ethernet Port | 2 (2.5G/1G/100M/10M) |
PCIe Slot | Slot 1: PCIe Gen 3 x2 |
USB 2.0 port | 2 |
USB 3.2 Gen 2 (10Gbps) Port | 2 x Type A USB 3.2 Gen 2 |
HDMI Output | 1, HDMI 1.4b |
Form Factor | 2U Short Depth Rackmount |
LED Indicators | HDD 1-8 Status LAN Expansion Power |
Buttons | Power, Reset |
Operating Temperature | 0 - 40 °C (32°F - 104°F) |
Power Supply Unit | 300W (x2), 100-240V |
Power Consumption | Disk Standby Mode: 31.742 Operating Mode: 55.83 W |
Fan | 3 x 60mm, 12VDC |
System Warning | Buzzer |
Standard Warranty | 3 Years |
Dimensions | 88.6 × 432 × 297.4 mm |
Package Contents | TS-864eU-RP Ethernet Cable x 1 Power Cord x 2 Flat head screw x 32 (for 3.5" HDD) Flat head screw x 24 (for 2.5" HDD) Quick Installation Guide (QIG) |
