Description
High-Performance Processing: This NAS is equipped with an AMD Ryzen™ 7 7000 Series 8-core/16-thread processor, capable of reaching speeds up to 5.3 GHz. This powerful processor ensures that the NAS can handle intensive enterprise applications and multitasking with ease, providing robust and reliable performance.
Flexible and Expandable Memory: The NAS comes with 32 GB of DDR5 UDIMM memory, which can be expanded up to 192 GB. It supports both non-ECC and ECC RAM, offering flexibility for various workloads and ensuring data integrity, making it suitable for critical business operations.
Versatile Storage Options: Featuring 16 drive bays that support both 3.5-inch SATA hard drives and 2.5-inch SATA SSDs, this NAS provides extensive storage capacity. Additionally, it includes two M.2 PCIe Gen 5 slots for NVMe SSDs, which can be used for SSD caching to enhance storage performance and speed.
Advanced Connectivity: The NAS is equipped with two 10GbE ports and two 2.5GbE ports, providing high-speed network connectivity. This setup is ideal for virtualization, large file transfers, and other bandwidth-intensive tasks, ensuring efficient and fast data access.
Enhanced Data Management with QuTS hero OS: Running on the QuTS hero operating system, based on the ZFS file system, this NAS offers advanced data management features such as inline data deduplication, compression, and real-time data integrity checks. These features optimize storage efficiency and ensure the security and reliability of your data.
Model | TS-h1677AXU-RP-R7-32G |
CPU | AMD Ryzen 7 7000 series 8-core/16-thread processor, burst up to 5.3 GHz |
Graphic Processors | AMD Radeon Graphics |
CPU Architecture | 64-bit x86 |
System Memory | 32 GB UDIMM DDR5 (1x 32 GB) |
Maximum Memory | 192 GB (4 x 48 GB) |
Memory Slot | 4 x UDIMM DDR5 Support optional ECC memory |
Flash Memory | 5GB (Dual boot OS protection) |
Drive Bay | 16 x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility |
3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
M.2 Slot | 2 x M.2 2280 PCIe Gen 5 x2 slots |
2.5 Gigabit Ethernet Port | 2 (2.5G/1G/100M/10M) |
10 Gigabit Ethernet Port | 2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
PCIe Slot |
3 Slot 1: Gen 4 x 4 Slot 2: Gen 4 x 8 or Gen 4 x 4 Slot 3: Gen 4 x 4 |
USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-A USB 3.2 Gen 2 10Gbps |
Form Factor | 3U Rackmount |
LED Indicators |
Power Status
HDD 1-16
M.2 SSD 1-2
Status
LAN
Storage expansion port status
|
Buttons | Power, Reset |
Operating Temperature | 0 - 40 °C (32°F - 104°F) |
Power Supply Unit | 550W(x2), 100-240V |
Power Consumption | Disk Standby Mode: 99.99 Operating Mode, Typical: 349.96 W |
Fan | System fan: 3 x 60mm, 12VDC |
System Warning | Buzzer |
Standard Warranty | 5 Years |
Dimensions | 131.3 × 482.2 × 550.8 mm |
Package Contents | TS-h1677AXU-RP 10Gbase-T Ethernet cable x 1 Flat head screw x 64 (for 2.5" HDD ) Flat head screw x 64 (for 3.5" HDD) Power cord x 2 Quick Installation Guide (QIG) |
