Description
About the item
- Reliable Pure Sine Wave Power: 1000VA/670W Line-Interactive UPS delivers pure sine wave output (230V), providing clean, consistent power ideal for sensitive IT equipment, servers, and networking devices.
- Extended Battery Runtime: Equipped with 2 x 11Ah built-in batteries, offering up to 20.6 minutes of backup at 50% load and 6 minutes at full load for safe system shutdowns.
- High Energy Efficiency: Operates with up to 96% efficiency, reducing energy consumption, heat generation, and overall operating costs for your business.
- Advanced Voltage Protection: Features Automatic Voltage Regulation (AVR) and a wide input voltage range (151-302V adjustable) to protect devices from power fluctuations without switching to battery.
- Smart Manageability: Includes USB, RS-232 serial, and SmartSlot interfaces for network management cards, plus PowerChute Business Edition software for automated shutdowns and remote monitoring.
- User-Friendly Monitoring: LED status indicators with load and battery bar graphs, along with audible alarms, provide clear, real-time insights into UPS performance.
- Comprehensive Surge Protection: Offers 320 Joules surge protection and full-time multi-pole noise filtering to safeguard your critical devices.
- User-Replaceable Battery: Designed for easy maintenance with a user-replaceable battery, extending the lifespan of your UPS.
- 1-Year Warranty: Backed by a 1-year manufacturer's warranty for reliable support and peace of mind.
Key Features:
-
Power Capacity: 1500VA / 980W – ideal for servers, storage, and networking equipment.
-
Input Voltage Range: 165–285V (extended: 151–302V) – optimized for Indian power conditions.
-
Output Voltage: 230V nominal with pure sine wave output.
-
Battery Backup: 2 x 17Ah sealed lead-acid batteries; 6.7 minutes at full load, 23.9 minutes at 50% load.
-
Connectivity: USB, DB-9 RS-232 serial port, and Smart-Slot for network management.
-
User Interface: LED indicators, load and battery bar graphs, and audible alarms.
-
Surge Protection: 480 Joules – protects against voltage spikes and surges.
-
Software Support: Compatible with PowerChute Business Edition for safe shutdown and energy management.
-
Design: Tower form factor (432 x 196 x 544 mm), 24.04 kg weight.
-
Certifications & Warranty: BIS certified; 2-year repair or replace warranty.
Specifications
| Category | Specification |
|---|---|
| Overview | |
| Lead Time | Usually in Stock |
| Main | |
| Product Type | Uninterruptible Power Supply (UPS) |
| Run Time for Load | 980 W |
| Load Range (Min–Max) | 98–980 W |
| Runtime (Full Load) | 6 minutes 41 seconds |
| Max Capacity Used | 100% |
| Configurable Output Voltage | 220 V / 230 V / 240 V |
| Complementary | |
| Communication Port Type | SmartSlot |
| Batteries & Runtime | |
| Battery Type | Lead-acid battery |
| Extended Runtime | No |
| Battery Filled Slots | 0 |
| Battery Free Slots | 0 |
| Battery Recharge Time | 3 hours |
| Battery Life | 2–4 years |
| Battery Charger Power | 136 W rated |
| General | |
| Provided Equipment | RS-232 Cable, USB Cable, User Manual |
| Power Module Slots | 0 |
| Redundant | No |
| Physical | |
| Height | 21.6 cm |
| Width | 17 cm |
| Depth | 43.9 cm |
| Product Weight | 24.04 kg |
| Mounting Mode | Not rack-mountable |
| Mounting Preference | No preference |
| Two Post Mountable | 0 |
| USB Compatible | No |
| Input | |
| Main Input Voltage | 230 V |
| Input Connection Type | IEC 60320 C14 |
| Input Voltage Limits | 151–302 V adjustable / 160–286 V |
| Network Frequency | 50/60 Hz ±3 Hz auto-sensing |
| Output | |
| Output Voltage | 230 V |
| Rated Power (W / VA) | 980 W / 1500 VA |
| Output Connection Type | 4 India 3-pin 6A |
| Harmonic Distortion | < 5% |
| Max Configurable Power (W / VA) | 980 W / 1500 VA |
| UPS Type | Line interactive |
| Wave Type | Sine wave |
| Output Frequency | 47–53 Hz (50 Hz sync) |
| Environmental | |
| Acoustic Level | 45 dBA |
| Heat Dissipation | 135 BTU/h |
| Operating Altitude | 0–10,000 ft |
| Operating Temp | 0–40 °C |
| Storage Temp | -15–45 °C |
| Storage Altitude | 0–15,240 m |
| Relative Humidity | 0–95% |
| Storage Humidity | 0–95% |
| Communications & Management | |
| Control Panel | LED status: On line, On battery, Replace battery, Overload |
| Alarm | On battery, Low battery (distinctive), Configurable delays |
| Surge Protection & Filtering | |
| Surge Energy Rating | 480 J |
| Noise Suppression | Full-time multi-pole filtering, 0.3% IEEE let-through, zero clamping, UL 1449 |
| Packing Units | |
| Package Type | PCE |
| Package Quantity | 1 |
| Package Dimensions (H × W × L) | 37 cm × 59 cm × 33 cm |
| Package Weight | 26.76 kg |
| Warranty | 2 years repair or replace |
