Description
24 Gigabit Ethernet Ports + 4 Fixed 1G Uplinks: Provides high-speed connectivity for access layer deployments in enterprise networks.
Layer 3 Switching Capabilities: Supports static routing, OSPF, EIGRP stub, and routed access for efficient network segmentation.
Advanced Security Features: Includes Cisco TrustSec, MACsec encryption, and Encrypted Traffic Analytics for secure and intelligent threat detection.
StackWise-160 Support: Allows stacking of up to 8 switches with 160 Gbps bandwidth for simplified management and scalability.
Modular Cisco IOS XE Software: Enables programmability, automation, and consistent policy enforcement across the network.
| Model | C9300L-24T-4G-E |
| Designed to replace | Catalyst 3850 |
| Supported IOS | Network Advantage, Network Essentials |
| Network modules options | Fixed Modules |
| Stack Technology | StackWise-320 |
| Stacking bandwidth | 320 Gbps |
| Total number of MAC addresses | 32,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 32,000 (24,000 direct routes and 8000 indirect routes) |
| IPv4 routing entries | - |
| IPv6 routing entries | 16,000 |
| Multicast routing scale | 8,000 |
| QoS scale entries | 5,120 |
| ACL scale entries | 5,120 |
| Packet buffer per SKU | 16 MB buffer for 24 and 48 port Gigabit Ethernet models |
| Flexible NetFlow (FNF) entries | 64,000 flow on 24- and 48-port Gigabit Ethernet models |
| DRAM | 8 GB |
| Flash | 16 GB |
| VLAN IDs | 4094 |
| Total Switched Virtual Interfaces (SVIs) | 1000 |
| Jumbo frames | 9198 bytes |
| Switching capacity | 56 Gbps - 176 Gbps |
| Forwarding rate | 41.66 Mpps - 130.95 Mpps |
| Warranty | Limited lifetime warranty By Cisco |
