A PRAMA bullet security camera with a white and black housing, featuring a blue PRAMA logo on the side, shown against a plain white background.

Prama PT-NC160D3-WNMS/AW(D2) 6MP Dual Light Bullet Camera | 3200×1800 | 30m | 120dB WDR | 512GB | PoE | IP67 | 1 Year Warranty

SKU: PT-NC160D3-WNMS/AW(D2)

In Stock
0 people are currently viewing this product
₹ 12,599
Taxes included. Free Shipping.
Exclusive Pricing Available
Connect with our team for personalised pricing and the latest available offers on this product. Contact us
4.6
(285 reviews)

ADD-ON PRODUCTS

COMPARE

DESCRIPTION

Prama PT-NC160D3-WNMS/AW(D2) 6MP Dual Light Bullet Camera | 3200 × 1800 | 30m | 120dB WDR | 512GB | PoE | IP67 | 1 Year Warranty

Product Description

The Prama PT-NC160D3-WNMS/AW(D2) is a 6MP Dual Light Fixed Bullet Network Camera designed for professional indoor and outdoor surveillance. It delivers up to 3200 × 1800 resolution and features Smart Dual Light technology with IR and white-light illumination up to 30 metres. The camera supports human and vehicle classification, H.265/H.264 compression, built-in two-way audio, onboard storage up to 512GB, and IP67 protection.

Available from Suntronix, a trusted Prama Dealer in Chennai, Tamil Nadu, with product availability and delivery across India.


About This Product

The Prama PT-NC160D3-WNMS/AW(D2) combines 6MP high-resolution imaging with Smart Dual Light technology for dependable surveillance in different lighting conditions. Its 1/2.4-inch Progressive Scan CMOS sensor supports a maximum resolution of 3200 × 1800, while the 4mm fixed lens provides a 78° horizontal field of view.

The camera supports 120dB WDR, BLC, HLC and 3D DNR for improved image quality. It also features human and vehicle classification, built-in microphone and speaker, flashing light, microSD storage up to 512GB, PoE, and IP67 protection.


Key Features

  • 6MP Dual Light Fixed Bullet Network Camera
  • 3200 × 1800 Maximum Resolution
  • 1/2.4-inch Progressive Scan CMOS
  • Smart Dual Light
  • IR + White Light
  • Up to 30m Supplement Light Range
  • Human & Vehicle Classification
  • 120dB WDR
  • Built-in Microphone
  • Built-in Speaker
  • Two-Way Audio
  • Flashing Light
  • H.265 / H.264 Compression
  • 512GB microSD Storage Support
  • IEEE 802.3af PoE
  • IP67 Protection
  • 4mm Fixed Lens
  • ONVIF Profile S, T & G

Storage

The Prama PT-NC160D3-WNMS/AW(D2) features a built-in memory card slot supporting microSD, microSDHC and microSDXC cards up to 512GB, providing convenient onboard recording storage.


Ideal Applications

The Prama PT-NC160D3-WNMS/AW(D2) is suitable for:

  • Homes & Apartments
  • Offices & Corporate Spaces
  • Retail Stores
  • Shops & Showrooms
  • Warehouses
  • Commercial Buildings
  • Educational Institutions
  • Industrial Facilities
  • Parking Areas
  • Outdoor Perimeter Security
  • Residential Communities
  • Professional CCTV Installations

Why Buy from Suntronix?

With over 25 years of industry experience, Suntronix provides genuine Prama security and surveillance solutions in Chennai, Tamil Nadu, and across India. Get professional assistance for IP cameras, NVRs, CCTV systems, surveillance storage and complete security solutions.

SPECIFICATION

Brand

Prama

Model

PT-NC160D3-WNMS/AW(D2)

Product Type

6MP Dual Light Fixed Bullet Network Camera

Image Sensor

1/2.4-inch Progressive Scan CMOS

Maximum Resolution

3200 × 1800

Shutter Time

1/3s to 1/100,000s

Minimum Illumination

Colour: 0.005 Lux @ F1.6, AGC ON
B/W: 0 Lux with IR

Day & Night

IR Cut Filter

Angle Adjustment

Pan: 0° to 360°
Tilt: 0° to 90°
Rotate: 0° to 360°

Lens Type

Fixed Focal Lens

Focal Length

4mm

Field of View

Horizontal: 78°
Vertical: 38°
Diagonal: 96°

Lens Mount

M12

Aperture

F1.6

DORI Distance

Detect: 115m
Observe: 45m
Recognize: 23m
Identify: 11m

Supplement Light Type

IR + White Light

Supplement Light Range

Up to 30m

Smart Supplement Light

Yes

IR Wavelength

850nm

Main Stream

Up to 20fps at 3200 × 1800, 2688 × 1520, 1920 × 1080 and 1280 × 720

Sub Stream

Up to 20fps at 1280 × 720, 640 × 480 and 640 × 360

Video Compression

Main Stream: H.265 / H.264
Sub Stream: H.265 / H.264 / MJPEG

Video Bit Rate

32Kbps to 16Mbps

Bit Rate Control

CBR / VBR

H.264 Profile

Baseline / Main / High Profile

H.265 Profile

Main Profile

Region of Interest

1 Fixed Region for Main Stream

Audio

Mono Sound

Built-in Microphone

Yes

Built-in Speaker

Yes, maximum power consumption 1.5W

Audio Sampling Rate

8kHz / 16kHz

Environment Noise Filtering

Yes

Audio Compression

G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC

Wide Dynamic Range

120dB WDR

SNR

≥52dB

Image Enhancement

BLC / HLC / 3D DNR

Privacy Mask

4 Programmable Polygon Privacy Masks

Target Classification

Human & Vehicle Classification

Network Interface

1 × RJ45 10/100M Self-Adaptive Ethernet Port

ONVIF

Profile S / Profile T / Profile G

Simultaneous Live View

Up to 6 Channels

Onboard Storage

microSD / microSDHC / microSDXC up to 512GB

Built-in Microphone

Yes

Built-in Speaker

Yes

Reset Key

Yes

Event Detection

Motion Detection with Human & Vehicle Target Classification, Video Tampering Alarm and Exception

Linkage

FTP/SFTP/NAS/memory card upload, surveillance centre notification, email, recording, capture, audible warning and flashing light

Power Supply

12VDC ±25%, 0.66A

PoE

IEEE 802.3af, Class 3

Maximum Power Consumption

12VDC: 7.92W
PoE: 9.5W

Material

Metal & Plastic

Protection Rating

IP67

Dimensions

178.7 × 66 × 69.1mm

Weight

Approximately 285g

Operating Temperature

-30°C to +60°C

Operating Humidity

95% or less, non-condensing

Flashing Light

Yes
