DESCRIPTION
PoE+ Capability: This switch features eight 802.3af/at-compliant PoE+ ports, each capable of delivering up to 30W of power. This makes it ideal for powering devices such as IP cameras, access points, and IP phones through a single Ethernet cable.
Generous PoE Budget: With a total PoE power budget of 150W, it can support multiple PoE devices simultaneously, making it suitable for small to medium-sized surveillance and networking setups.
Full Gigabit Ports: Includes eight gigabit PoE+ ports and two gigabit SFP slots, providing high-speed connections and flexibility for fiber uplink connections.
Advanced Management Features: Integrated into the Omada SDN platform, it offers centralized cloud management, Zero-Touch Provisioning (ZTP), and intelligent monitoring, making network management more convenient and efficient.
Robust Security and QoS: Supports advanced security strategies like IP-MAC-Port Binding, ACL, and 802.1X, along with L2/L3/L4 QoS and IGMP snooping to optimize voice and video applications.
| Model | TL-SG2210MP |
| Standards and Protocols | IEEE 802.3i IEEE 802.3u IEEE 802.3ab IEEE802.3z IEEE 802.3ad IEEE 802.3x IEEE 802.3af IEEE 802.3at IEEE 802.3az IEEE 802.1d IEEE 802.1s IEEE 802.1w IEEE 802.1q IEEE 802.1x IEEE 802.1p |
| Interface | 8× 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX) 2× 100/1000 Mbps SFP Slots |
| Network Media |
10BASE-T: UTP/STP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP/STP category 5, 5e or above cable (maximum 100m)
100BASE-FX: MMF, SMF
1000BASE-X: MMF, SMF
|
| Fan Quantity | 1 |
| PoE Ports (RJ45) | Standard: 802.3at/af compliant PoE+ Ports: 8 Ports PoE Power Budget: 150 W* |
| Power Supply | 100-240V AC, 50/60Hz |
| Max. Power Consumption | V1: 173.9 W (110 V/60 Hz) (with 150 W PD connected); 12.2 W (110 V/60 Hz) (no PD connected) V2: 169.5 W (220 V/50Hz) (with 150 W PD connected) V3: 175.3 W (110 V/60Hz) (with 150 W PD connected) V4: 174.2 W (110V/60Hz) (with 150 W PD connected) |
| Max Heat Dissipation |
V1: 41.63 BTU/h (with no PD connected); 539.35 BTU/h (with 150 W PD connected)
V2: 578.42 BTU/hr (220V/50 Hz) (with 150 W PDconnected)
V3: 597.8 BTU/hr (110 V/60 Hz) (with 150 W PD connected)
V4: 594.46 BTU/hr (110V/60Hz) (with 150 W PD connected)
|
| Switching Capacity | 20 Gbps |
| Packet Forwarding Rate | 14.9 Mpps |
| Advanced Features |
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
|
| Dimensions | 294 x 180 x 44 mm |
| Package Content |
TL-SG2210MP
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet
|
| Warranty |
3 Year Brand Warranty
|
